40kN Vibration Shaker for Avionics Testing 1500x1500mm Table

40kN Vibration Shaker for Avionics Testing 1500x1500mm Table

Brand Name: PRECISION
Model Number: VTS-40
MOQ: 1
Price: $6000
Payment Terms: T/T
Supply Ability: 100/month
Detail Information
Place of Origin:
CHINA
Certification:
CE ISO
Customized Support:
OEM ODM
Sine Force:
40kN
Random Force:
40kN
Shock Force:
80kN
Frequency Range:
1-3000Hz
Displacement:
100mm
Velocity:
2.0
Table Size:
1500x1500mm
Packaging Details:
Standard export packaging
Supply Ability:
100/month
Highlight:

high-power vibration shaker for avionics

,

vibration test system with altitude simulation

,

electrodynamic shaker for avionics testing

Product Description

High-Power Vibration Shaker for Avionics Testing Altitude Simulation



Our High-Power Vibration Shaker for Avionics Testing is a state-of-the-art integrated system designed for the rigorous qualification of aerospace electronics. This cutting-edge solution combines a powerful vibration shaker with an advanced Altitude Simulation Test Chamber, allowing you to subject critical avionics to the precise dynamic stresses and atmospheric conditions encountered during flight. By replicating the punishing vibrations of engines and airframes while simultaneously simulating high-altitude pressure, our system is indispensable for ensuring the unwavering reliability and safety of your avionics in the most challenging environments.



Key Features



  • Integrated Multi-Stress Testing: Conducts simultaneous vibration and altitude simulation in a single, seamless operation. This provides the most realistic and accelerated assessment of avionics performance under synergistic stresses.

  • High-Power Vibration: Our high-force electrodynamic shaker delivers the power needed to test large and heavy avionics racks, payloads, and structural components, providing accurate and repeatable vibration profiles that meet stringent aerospace standards like MIL-STD-810G and RTCA DO-160.

  • Accurate Altitude Simulation: The integrated chamber precisely simulates pressure variations from sea level to very high altitudes (e.g., up to 100,000+ feet). This is crucial for evaluating the effects of reduced air pressure on electronic components, connectors, and materials.

  • Wide Temperature Range (Optional): Many configurations offer an extended temperature range within the altitude chamber (e.g., -70°C to +180°C), enabling combined testing of vibration, altitude, and extreme temperatures.

  • Advanced Integrated Control System: A powerful controller seamlessly synchronizes vibration profiles with altitude pressure cycles (and temperature, if equipped), allowing for the programming of complex, real-world flight simulation test sequences.

  • Comprehensive Data Acquisition: Continuously monitors and records all environmental parameters (altitude, temperature) and vibration data (acceleration, displacement), providing detailed insights for analysis and compliance reports.

  • Robust Construction: Built with aerospace-grade components and a vacuum-tight chamber designed for long-term reliability under continuous, demanding operation.

  • Customizable Test Fixtures: Our engineering team designs and manufactures application-specific fixtures to securely mount diverse avionics units, ensuring optimal stress transmission and test integrity.

Technical Specifications



  • Rated Sine/Random/Shock Force: 4,000 kgf / 4,000 kgf / 8,000 kgf

  • Armature Mass: 35 kg

  • Frequency Range: 5–3,000 Hz

  • Inserts Size (Standard): M10

  • Max./Continuous Displacement p-p: 100mm / 90mm

  • Load Attachment Points (Standard): 17

  • Max. Velocity: 1.8 m/s

  • Natural Frequency - Thrust Axis: <3Hz

  • Max. Sine/Random Acceleration: 100g / 60g

  • Max. Vertical Load Support: 500 kg

  • Armature Diameter: 440 mm

  • Stray field @152 mm above table: ≤1mT (10 gauss)

  • Fundamental Resonance Frequency: 2,500Hz(nom.) ±5%

  • Dimension (L x W x H): 1,270 mm x 980mm x 1,135mm

  • Allowable Armature Overturning Moment: 500 Nm

  • Weight (Uncrated): 2,500 kg



40kN Vibration Shaker for Avionics Testing 1500x1500mm Table 040kN Vibration Shaker for Avionics Testing 1500x1500mm Table 1

Applications



  • Avionics Qualification: Comprehensive testing of flight control systems, communication equipment, navigation systems, and displays under combined vibration and altitude conditions.

  • Altitude Performance Evaluation: Assessing the operational performance and reliability of avionics at various simulated altitudes.

  • Decompression Testing: Evaluating the ability of avionics to withstand rapid decompression events.

  • Vibration During Flight Phases: Simulating the specific vibration profiles encountered during different phases of flight under varying atmospheric pressures.

  • Regulatory Compliance: Meeting stringent aerospace industry standards and regulations (e.g., RTCA DO-160, MIL-STD-810).

  • Research & Development: Accelerating the development cycle for new avionics technologies by understanding their behavior in realistic flight environments.



Benefits



  • Unrivaled Flight Simulation: Provides the most accurate and comprehensive assessment of avionics performance under combined environmental and dynamic stresses.

  • Enhanced Safety & Reliability: Proactively identifies potential failure points related to altitude and vibration, ensuring the safety and reliability of critical flight systems.

  • Accelerated Qualification: Streamlines the complex aerospace qualification process, significantly speeding up time-to-market.

  • Comprehensive Data Insights: Generates rich, synchronized data for in-depth analysis, contributing to superior design optimization and robust validation reports.

Ready to ensure the peak performance and safety of your aerospace avionics? Contact our experts today to discuss your requirements for a High-Power Vibration Shaker with Altitude Simulation.
