Steel Construction Humidity And Temperature Stability Chambers For Refrigerators

Brand Name:	PRECISION
Model Number:	THC-270
MOQ:	1
Price:	$6000
Payment Terms:	T/T
Supply Ability:	100/month

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

ISO

Customized Support:

OEM ODM

Origin:

China

Material:

Stainless Steel

Controller:

Programmable LCD Touch Screen

Temp Accuracy::

0.5°C

Temp Uniformity:

0.5°C

Refrigerant:

Environmental Friendly R23/R404

Packaging Details:

Standard export packaging

Supply Ability:

100/month

Highlight:

Steel Construction Thermal Humidity Chamber

Humidity And Temperature Chambers For Refrigerators

Product Description

Cost - Effective Humidity And Temperature Stability Test Chambers for Refrigerators

1. Introduction

Refrigerators are a staple in households and commercial settings, responsible for preserving food and other perishable items. Ensuring the humidity and temperature stability within a refrigerator is crucial for maintaining the quality and shelf - life of the stored products. Our cost - effective humidity and temperature stability test chambers for refrigerators are designed to meet the testing needs of refrigerator manufacturers, quality control departments, and research institutions. These test chambers offer a reliable and efficient way to evaluate the performance of refrigerators under various conditions, while also being budget - friendly.

2. Key Features

2.1 Cost - Effective Design

We understand the importance of cost - efficiency in the manufacturing and testing processes. Our test chambers are designed using cost - effective materials and components without compromising on performance. The manufacturing process is optimized to reduce production costs, and the overall design is energy - efficient, resulting in lower operating costs. This makes our test chambers an attractive option for businesses of all sizes, from small - scale manufacturers to large - scale enterprises.

2.2 Precise Humidity and Temperature Control

The test chambers are equipped with advanced control systems that allow for precise regulation of humidity and temperature. The temperature can be accurately set and maintained within a wide range, typically from - 70°C to 150°C for the freezer section and 2°C to 8°C for the refrigerator section, with a precision of ±0.5°C. Humidity levels can be adjusted from 30% to 90% relative humidity (RH), with a precision of ±5% RH. This high level of precision ensures that the refrigerators are tested under realistic and controlled conditions, enabling accurate evaluation of their performance.

2.3 Customizable Test Environments

Refrigerators are used in a variety of settings, and their performance can be affected by different environmental factors. Our test chambers offer customizable test environments to simulate various real - world conditions. Users can program different temperature and humidity profiles, including cyclic changes, to mimic the conditions a refrigerator might encounter in different climates or usage scenarios. This flexibility allows for comprehensive testing of the refrigerator's ability to maintain stable conditions under different circumstances.

2.4 Large - Capacity Interior

To accommodate different sizes and types of refrigerators, our test chambers feature a large - capacity interior. The chambers are designed to easily fit standard - sized household refrigerators as well as commercial units. The interior space is well - organized, with adjustable shelves and fixtures to ensure proper placement and positioning of the refrigerators during testing. This large - capacity design enables efficient testing of multiple refrigerators simultaneously, increasing productivity and reducing testing time.

2.5 Durable Construction

The test chambers are built to last. The exterior is constructed from high - quality, durable materials that are resistant to corrosion, impact, and wear. The interior is lined with materials that are easy to clean and maintain, ensuring a hygienic testing environment. The components, such as the heating, cooling, and humidity control systems, are sourced from reliable suppliers and are rigorously tested to ensure long - term performance and reliability.

2.6 User - Friendly Interface

Our test chambers are equipped with a user - friendly interface that makes it easy to operate and monitor the testing process. The control panel is intuitive, with clear displays and easy - to - use buttons for setting temperature, humidity, and other test parameters. The interface also provides real - time information on the current conditions inside the chamber, as well as the status of the testing process. Additionally, the test chambers can be connected to a computer or a mobile device for remote monitoring and control, allowing users to manage the tests from anywhere.

3. Specifications

Model	THC-225	THC-408	THC-800	THC-1000
Inside dimension(W x D x H) mm	50 x 75 x 60	60 x 85 x 80	100 x 100 x 80	100 x 100 x 100
Outside dimension(W x D x H) mm	75 x 165 x 170	85 x 175 x 190	125 x 190 x 190	125 x 190 x 210
Internal material	#304 Stainless Steel
External material	Powder coated #304 Stainless Steel
Temperature range	+ 150℃~ - 70 ℃
Humidity range	5% ~ 98% R. H
Temperature resolution ℃	0.01
Humidity resolution % R. H.	0.1
Temperature stability ℃	±0.3
Humidity stability % R. H.	±2
High temperature ℃	100	100	100	100
Heating time (min)	20	30	30	30
Low temperature	0, -40, -70	0, -40, -70	0, -40, -70	0, -40, -70
Cooling time (min)	20, 50, 70	20, 50, 70	20, 50, 70	20, 50, 70
Air circulation system	Mechanical convection system
Cooling system	Imported compressor, fin evaporator, gas condenser
Heating system	Sus304 Stainless steel High-speed heater
Humidification system	Steam Generator
Humidification water supply	Reservoir, Sensor-controller solenoid valve, recovery-recycle system
Controller	Touch panel
Electrical power requirements	Please contact us for requirements of specific models
Safety device	Circuit system load protection, compressor load protection, control system load protection, humidifier load protection, overtemperature load protection, fault warning light

4. Benefits for Refrigerator Manufacturers and Testers

4.1 Cost Savings

The cost - effective design of our test chambers allows manufacturers and testers to save on both the initial investment and long - term operating costs. The energy - efficient operation reduces electricity consumption, and the durable construction minimizes the need for frequent repairs and replacements. This results in significant cost savings over the lifespan of the test chamber, making it a cost - effective solution for testing refrigerators.

4.2 Improved Product Quality

By subjecting refrigerators to precise and controlled humidity and temperature conditions, manufacturers can identify and address potential performance issues early in the production process. This leads to improved product quality, as the refrigerators are better able to maintain stable conditions and preserve the freshness of the stored items. The customizable test environments also allow for comprehensive testing, ensuring that the refrigerators are reliable and perform well in different real - world scenarios.

4.3 Regulatory Compliance

The refrigerator industry is subject to various regulations regarding temperature and humidity control, energy efficiency, and product safety. Our test chambers are designed to help manufacturers comply with these regulations by providing accurate and reliable testing data. The precise control of humidity and temperature ensures that the refrigerators meet the required standards, enabling manufacturers to obtain the necessary certifications and sell their products in different markets.

4.4 Enhanced Research and Development

For research and development teams, our test chambers provide a valuable tool for exploring new technologies and designs in refrigeration. The ability to customize the test environments and precisely control the humidity and temperature allows researchers to study the performance of new components, such as compressors, evaporators, and insulation materials. This can lead to the development of more energy - efficient and reliable refrigerators, giving manufacturers a competitive edge in the market.

4.5 Increased Productivity

The large - capacity interior of our test chambers allows for the testing of multiple refrigerators simultaneously, increasing productivity and reducing testing time. The user - friendly interface and remote monitoring and control features also make it easier to manage the testing process, allowing testers to focus on other tasks while the tests are running. This increased productivity helps manufacturers to bring their products to market faster and more efficiently.

5. Applications

5.1 Product Development

During the product development phase, refrigerator manufacturers use our test chambers to evaluate new models and prototypes. By testing the refrigerators under different humidity and temperature conditions, engineers can assess their performance, energy consumption, and stability. This helps in making design improvements and ensuring that the final product meets the desired specifications.

5.2 Quality Control

In the manufacturing process, the test chambers are used for quality control purposes. A sample of refrigerators from each production batch is tested in the chamber to ensure that they meet the specified quality standards. The precise control of humidity and temperature allows for accurate evaluation of the refrigerators' ability to maintain stable conditions, and any issues can be identified and addressed before the products are shipped to the market.

5.3 Energy Efficiency Testing

With the increasing focus on energy efficiency in the refrigerator industry, our test chambers are used to measure the energy consumption of refrigerators under different operating conditions. The customizable test environments allow for the simulation of real - world usage scenarios, enabling manufacturers to accurately evaluate the energy efficiency of their products. This information can be used to improve the design of the refrigerators and meet the energy efficiency standards set by regulatory bodies.

5.4 Research on New Technologies

Research institutions and refrigerator manufacturers use our test chambers to conduct research on new technologies and materials in refrigeration. The ability to precisely control the humidity and temperature allows for in - depth studies of the performance of new components and designs. This research can lead to the development of more advanced refrigeration technologies, such as improved insulation materials, more efficient compressors, and better humidity control systems.

6. Conclusion

Our cost - effective humidity and temperature stability test chambers for refrigerators are a valuable asset for the refrigerator industry. With their precise control, customizable test environments, large - capacity interior, and user - friendly interface, these test chambers provide a comprehensive and efficient solution for testing the performance of refrigerators. Whether it's for product development, quality control, energy efficiency testing, or research on new technologies, our test chambers can help manufacturers and testers to ensure the quality, reliability, and energy efficiency of their refrigerators. Contact us today to learn more about how our test chambers can meet your specific testing needs.
