| Place of Origin: | China |
|---|---|
| Brand Name: | AISRY |
| Certification: | ISO |
| Model Number: | ASR-5027 |
| Minimum Order Quantity: | 1 set |
| Price: | USD 1000-10000 |
| Packaging Details: | Standard export wooden case |
| Delivery Time: | 15 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 200 sets per month |
| Nternal Dimension: | 400 × 330 × 170 (W × H × D) Mm | Material Of Inner And Outer Box: | SUS304 |
|---|---|---|---|
| Insulation Layer: | PV Styrofoam | Timing Function: | 1 ~ 9999H/M/S |
| Control Accuracy: | ± 0.5 ℃ | Application: | Steam Aging Tester |
| Material: | SUS 304 Stainless Steel | Warranty: | 1 Year |
| Highlight: | 2KW Drawer steam aging tester,SUS304 Environmental Test Chamber,Drawer Steam Aging Test Chamber |
||
Environmental Test Chamber Drawer Steam Aging Chamber
Application :
This machine is used in electronic connector, semiconductor IC, transistors, diodes, LCD LCD, chip resistance capacitance and components industry electronic components metal pin wetting resistance test before the aging accelerated life time test.
Features :
1 Having safety device, including multi over-temperature protection and power off when out of water.
2 Testing high temperature/high humidity to spare pares, components.
3 Digital electronic indicators + S. S. R with PID automatic calaulation capabilitty.
4 Have time planning function, the maximum setting is 9990 minutes.
Technical Parameters:
| Inner box size(W*H*D) | 500*400*200MM |
| Carton size(W*H*D) | 600*500*420MM |
| Steam temperature | Up to 97 |
| Controller | PID+SCR |
| Heating time | about 45 minutes |
| Control accuracy | 0.5 |
| Timer | 9999H |
| Voltage | 220V |
| power | 2KW |
