Programmable 150L Temperature And Humidity Testing Chamber

Basic Information
Place of Origin: China
Brand Name: AISRY
Certification: ISO
Model Number: ASR-80L
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden case
Delivery Time: 15 work days
Payment Terms: T/T, Western Union
Supply Ability: 200 sets per month
Detail Information
Humidity Range: 20% To 98% RH +/- 0.5% Temperature Range: -40 ℃ ~ 150 ℃ Is Available On Request
Temperature Control Mode: Balance Temperature Control (BTC) Mode Working Environment Temperature: 5 ℃ -35 ℃
Heating Rate: 4.0 ℃/ Min Cooling Rate: 1.2 ℃/ Min
Thermal Insulation Material: Polyurethane Foam (glass Wool) Temperature Fluctuation: ≤0.5°C
High Light:

150L environmental control chamber


225L laboratory test chamber


800L environmental simulation chamber

Product Description

GJB150 Programmable Constant Temperature and Humidity Testing Chamber


Application :

Temperature and humidity testing machine has conditioning system that be able to offer quick and constant conditions from 5% to 98% R.H. +/- 0.5% and-70°C to 150°C +/-0.5°C, is widely used for the resistance test to heat, cold, dry, and humidity etc, and used for the conditioning of many kinds of samples prior to testing.



It is designed for testing the capability of heat-endurance, cold-endurance, dryness-endurance, and humidity-endurance, suitable for quality control of the industries of electron, electrical equipment, vehicle, metal, foodstuffs, chemistry, building materials, luggage, adhesion tape, printing, packaging, etc.



Specification :

Model ASR-80L
Inner size: WHD(cm) 40*50*40 50*60*50 60*75*50 60*85*80 100*100*80 100*100*100
External size: WHD(cm) 105*165*98 105*175*108 115*190*108 135*200*115 155*215*135 155*215*155
Temperature range (Low:A:+25℃; B:0℃;C:-20℃; D:-40℃;E:-60℃;F:-70℃) (High:+100℃/+150℃)
Humidity range 20%~98% R.H.(10%~98%R.H);(5%~98%R.His special optional condition)
Temp analytic accuracy/
Temperature Fluctuation ±0.5℃
Humidity analytic accuracy/ Humidity control accuracy ±0.1%;±2.5%
Heat; cooling time Heat up about 4.0°C/min ; Cooling about 1.0°C/min
Inner and outer materials SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer
Insulation materials Resistant to high temp ,high density,formate chlorine,ethyl acetum foam insulation materials
Cooling system

Air cooling/single segment compressor(-40°C) ,air and water double segment compressor


Protection devices

Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch,

super humidity over-temperature protection switch, fuse, failure warning system

Parts Watching window , 50mm testing hole , PL internal bulbs , Wet and dry bulb gauze , partition plate , castorx4,Foot Cupx4
Compressor Original France“Tecumseh”brand
Controller TEMI South Korea
Power AC220V 50/60Hz & 1, AC380V 50/60Hz 3
weight (kg) 150 220 270 320 450 580
